Vertical Sump Slurry Pump – SV

The Vertical Sump Slurry Pump – SV is a cantilever-type vertical centrifugal slurry pump designed for continuous handling of abrasive and high-density slurry in sump and pit applications. The vertical arrangement allows the pump to operate directly in the sump without submerged bearings or a conventional gland water system, making it suitable for applications where conventional horizontal pump suction arrangements are difficult to maintain. The SV configuration uses wear-resistant metal wet-end components for abrasive-duty slurry handling and incorporates a double-suction impeller to help reduce axial loading. The pump is suitable for mining, coal washing, mineral processing, metallurgy, sand and gravel handling, and industrial processes involving solid-containing liquids. Its modular bearing assembly and accessible structure also simplify inspection and routine maintenance.

Key word:

Slurry Pumps,Gravel Sand Pumps

Category:

Vertical Slurry Pump

E-mail

info@slurrypump-hb.com

Get Technical & Price Quote

Need help selecting model? Contact our engineer.

Products detail

detail

Product Overview

The Vertical Sump Slurry Pump – SV is designed for handling abrasive and high-density slurry collected in sumps and pits.

Unlike conventional horizontal slurry pumps, the vertical arrangement allows the wet end to operate directly in the slurry sump. The cantilever structure eliminates the need for submerged bearings, while the pump operates without a conventional gland water system.

The SV configuration uses wear-resistant metal wet-end components for abrasive-duty applications and is suitable for continuous slurry handling in mining and industrial processes.

Typical applications include:

Mining and mineral processing
Coal washing
Metallurgical processing
Sand and gravel handling
Industrial wastewater containing solids
Slurry collection and transfer

Key Features of SV Vertical Sump Pump

Cantilever Vertical Design

The bearing assembly is positioned above the slurry, while the pump wet end operates inside the sump. This cantilever arrangement eliminates submerged bearings and helps reduce exposure of the bearing assembly to abrasive slurry.

No Conventional Gland Water

The pump operates without a conventional gland water system, reducing auxiliary water requirements and simplifying the sealing arrangement.

Wear-Resistant Metal Wet End

The SV configuration uses wear-resistant metal wetted components for abrasive-duty slurry handling.

Main wetted components include:

Impeller
Pump casing
Strainers
Other wetted components

Material selection should consider slurry concentration, particle size, abrasiveness, impact conditions, and operating temperature.

Double-Suction Impeller

The double-suction impeller provides flow entry from both sides and helps reduce axial loading on the bearing assembly. The hydraulic design provides suitable flow passages for slurry containing solid particles.

Easy Maintenance

The modular bearing assembly and accessible vertical structure simplify inspection and replacement of selected pump components, helping reduce maintenance downtime.

SV and SVR Configurations

The SV and SVR configurations provide different wet-end material solutions within the vertical sump pump range.

SV uses wear-resistant metal wet-end components and is intended for abrasive-duty slurry applications where metal wear and impact resistance are required.

SVR uses an elastomer-lined wet end and is intended for applications where rubber lining is preferred according to the slurry characteristics.

The appropriate configuration should be selected according to slurry abrasiveness, particle size, concentration, temperature, and other operating conditions.

Typical Applications

Mining and Mineral Processing

Suitable for:

Sump slurry transfer
Mineral slurry handling
Process slurry circulation
Abrasive sump drainage

Coal Washing

Used for coal slurry, solid-containing process water, and slurry collected in process sumps.

Metallurgical Processing

Suitable for abrasive process slurry and solid-containing process fluids.

Sand and Gravel Handling

Used for sand slurry, sediment, and abrasive solid-particle transportation.

Pump Structure

The main components include:

Bearing assembly
Shaft
Column assembly
Pump casing
Double-suction impeller
Strainers
Discharge pipe

The bearing assembly remains above the slurry while the wet end is positioned inside the sump. The vertical cantilever structure allows the pump to operate without a lower submerged bearing.

Technical Data

SV/SVR Series Sump Pumps Main Technical Data
TYPE	ALLOWABLE MAX POWER (KW)	MATERIAL		CLEAR WATER PERFORMANCE					IMPELLER
		LINER	IMPELLER	FLOW		HEAD (m)	SPEED (r/min)	MAX EFF (%)	VANES	IMPELLER DIA. (mm)
		LINER	IMPELLER	（㎥/h）	(L/s)	HEAD (m)	SPEED (r/min)	MAX EFF (%)	VANES	IMPELLER DIA. (mm)
40PV-SV	15	M	M	19.44-43.2	5.4-12	4.5-28.5	1000-2200	40	5	188
40PV-SVR	15	RU	RU	17.28-39.6	4.8-11	4-26	1000-2200	40	5	188
65QV-SV	30	M	M	23.4-111	6.5-30.8	5-29.5	700-1500	50	5	280
65QV-SVR	30	RU	RU	22.5-105	6.25-29.15	5.5-30.5	700-1500	51	5	280
100RV-SV	75	M	M	54-289	15-80.3	5-35	500-1200	56	5	370
100RV-SVR	75	RU	RU	64.8-285	18-79.2	7.5-36	600-1200	62	5	370
150SV-SV	110	M	M	108-479.16	30-133.1	8.5-40	500-1000	52	5	450
200SV-SV	110	M	M	189-891	152.5-247.5	6.5-37	400-850	64	5	520
250TV-SV	200	M	M	261-1089	72.5-302.5	7.5-33.5	400-750	60	5	575
300TV SV	200	M	M	288-1267	80-352	6.5-33	350-700	50	5	610

Note: Actual performance depends on pump model, impeller configuration, operating speed, slurry characteristics, installation depth, and operating conditions.

Advantages

✅Cantilever vertical centrifugal design

✅No submerged bearings

✅No conventional gland water system

✅Wear-resistant metal wet-end components

✅Double-suction impeller

✅Suitable for abrasive and high-density slurry

✅Suitable for sump and pit applications

✅Modular bearing assembly

✅Convenient maintenance

✅SV and SVR material configurations available

Frequently Asked Questions

Q1: What is a vertical sump slurry pump used for?

👉It is used for handling abrasive and high-density slurry collected in sumps and pits, particularly in mining, mineral processing, coal washing, metallurgy, and other industrial applications.

Q2: What is the difference between SV and SVR?

👉SV uses wear-resistant metal wet-end components for abrasive-duty applications, while SVR uses an elastomer-lined wet end where rubber lining is preferred.

Q3: Does the pump require gland water?

👉No. The pump operates without a conventional gland water system.

Q4: Can it handle abrasive slurry?

👉Yes. The SV configuration uses wear-resistant metal wetted components designed for abrasive slurry containing mineral solids and other particles.

Q5: How should the pump be selected?

👉Selection should consider required flow, head, slurry concentration, particle size, abrasiveness, sump depth, operating speed, and material requirements.

Conclusion

The Vertical Sump Slurry Pump – SV is designed for reliable slurry handling in sump and pit applications.

Its cantilever vertical structure eliminates submerged bearings, while the SV metal wet-end configuration provides a practical solution for abrasive-duty slurry. The pump is suitable for mining, mineral processing, coal washing, metallurgy, sand and gravel handling, and other solid-containing industrial processes.
